MODEL |
HXJ135 |
|
|
Structure type |
Skid module type |
|
|
Workover depth (ft) （31/2″DP） |
15000 |
|
|
Drilling depth (ft) （5″DP） |
6562 |
|
|
Max. hook load (lbf) |
300000 |
|
|
Engine model |
C18 |
|
|
Engine power (hp) |
676 650 |
|
|
Transmission box model |
S5610H |
|
|
Transmission type |
Hydraulic +mechanical |
|
|
Derrick structure/ Height (ft) |
K type /95,102，108 |
|
|
Traveling system |
5×4 |
|
|
Drilling line diameter (in) |
1 |
|
|
Rotary table model |
ZP175 |
|
|
Traveling block model |
YG135 |
|
|
Swivel model |
SL135 |
|
|
Rated power of mud pump (hp) |
500 |
|
|
Substructure height (ft) |
19 |
|
|
Working environment |
Limit wind speed (knot) |
107（without setback） 93（full setback） |
|
Earthquake magnitude |
8 |
|
|
Temperature ℃ |
-20～+40 |
|
|
Relative humidity |
≤98% |
|
