MODEL

HXJ180

HXJ180DB

HXJ180DZ

Structure type

Skid module type

Workover depth (ft)
(31/2″DP)

21000

Drilling depth (ft)
(5″DP)

9100

Max. hook load (lbf)

400000

Engine model

2 ×C11

YZ23

YZ47B

Engine power (hp)

2 ×361

804

Transmission box model

2 × S5610H

JFD300/JS300

Transmission type

Hydraulic +mechanical

VFD+ mechanical

SCR+ mechanical

Derrick structure/
Height (ft)

K type /108

Tower type/102、108

Traveling system

5×4/6×5

Drilling line diameter (in)

1 1/4

Rotary table model

ZP275

Traveling block model

YG180/ YG225

Swivel model

SL225

Rated power of mud pump (hp)

800/1000

Substructure height (ft)

20/21

12

Working environment

Limit wind speed (knot)

107(without setback)
93(full setback)

Earthquake magnitude

8

Temperature ℃

-20~+40

Relative humidity

≤98%
