| Model | Power (W) | Resistance rangeΩ | Dimensions(mm) | Weight(g） | ||||||||
| L | L1 | L2 | ⌀D | H | T | ⌀D | B1 | B | ||||
| RXHG-A-80 | 80 | 1-13 | 140± 3.2 | 170 ± 4 | 184 ± 4 | 30 ± 3 | 59 ± 3 | 6 ± 1 | 3.5 | 5.5 | 30 | 263 |
| RXHG-A-100 | 100 | 1-18 | 170 ± 3.5 | 200± 4 | 214 ± 4 | 30 ± 3 | 59 ± 3 | 6 ± 1 | 3.5 | 5.5 | 30 | 290 |
| RXHG-A-150 | 150 | 1-22 | 245 ± 4 | 245 ± 4 | 259 ± 4 | 30 ± 3 | 59 ± 3 | 6 ± 1 | 3.5 | 5.5 | 30 | 395 |
| RXHG-A-200 | 200 | 1-30 | 266 ± 3 | 297 ± 4 | 308 ± 4 | 30 ± 3 | 72 ± 3 | 9 ± 1 | 4 | 6.5 | 26 | 485 |
| RXHG-A-300 | 300 | 1-36 | 266 ± 3 | 298 ± 4 | 310 ± 4 | 36 ± 3 | 82 ± 3 | 9 ± 1 | 4 | 6.5 | 35 | 640 |
| RXHG-A-400 | 400 | 1-47 | 250 ± 2 | 281 ± 3 | 298 ± 4 | 54 ± 3 | 98 ± 3 | 16 ± 1 | 8 | 6.5 | 50 | 1000 |
| RXHG-A-500 | 500 | 1-56 | 300 ± 2 | 331 ± 3 | 348 ± 4 | 54 ± 3 | 98 ± 3 | 16 ± 1 | 8 | 6.5 | 50 | 1350 |
