□ Suitable for use as short-term energy absorbing components in inverters, power electronics and communication devices. It can also be used as a partial pressure, shunt and load component. It is widely used in high requirements and harsh environments such as power supply, inverter and servo.
□ Can produce products that meet RoHS and REACH requirements
□ It is integrated with flame retardant material and has good vibration resistance.
□ Non-inductive products can be negotiated
□ There are two installation methods, two kinds of extraction methods, which are convenient for users to select. According to the installation method, it is divided into A type, B type, C type and D type. The A type, C type and D type resistors are horizontal installation structures, and the B type resistors are vertical installation structures. The resistor is one-end lead-out mode. According to the form of the lead-out line, it is divided into R type and Y type, R type is the soft lead lead-out mode, and Y type is the metal piece lead-out mode.
□ Product standard: Q/RW507-2014 "Detailed specification of RXLG aluminum shell wirewound fixed resistor"
□ Outline structure, size and performance parameters
|
Model
|
power (W)(25C)(With heat
sink)
|
Dimensions(mm)
|
Resistance rangeΩ
|
Cross-sectional area（mm2）
|
Recommended standard
heat sink (cm2) thickness 3mm
|
|
L1
|
L2
|
L3
|
W
|
H
|
A
|
|
RXLG-50
|
50
|
68
|
76
|
90
|
40
|
20.00
|
5.50
|
2-5.1
|
1.2
|
824
|
|
RXLG-60
|
60
|
85
|
98
|
115
|
40
|
20
|
5.5
|
2-5.1
|
1.2
|
10000
|
|
RXLG-80
|
80
|
110
|
122
|
140
|
40
|
20
|
5.5
|
2-5.1
|
1.2
|
10000
|
|
RXLG-100
|
100
|
135
|
148
|
165
|
40
|
20
|
5.5
|
2-5.1
|
1.2
|
10000
|
|
RXLG-120
|
120
|
155
|
175
|
190
|
40
|
20
|
5.5
|
5.1-5.6
|
1.2
|
1000
|
|
RXLG-150
|
150
|
185
|
197
|
215
|
40
|
20
|
5.5
|
5.1-5.6
|
1.2
|
1000
|
|
RXLG-200
|
200
|
130
|
155
|
167
|
60
|
30
|
5
|
4-6.8
|
2
|
3755
|
|
RXLG-300
|
300
|
180
|
210
|
230
|
60
|
30
|
4
|
4-10
|
2
|
4755
|
|
RXLG-400
|
400
|
230
|
245
|
260
|
60
|
30
|
5.3
|
4-10
|
2
|
5795
|
|
RXLG-600
|
600
|
285
|
320
|
335
|
60
|
30
|
5.3
|
4-10
|
2
|
5795
|
|
RXLG-700
|
700
|
350
|
385
|
400
|
60
|
30
|
5.3
|
4-10
|
2
|
5795
|
