MODEL |
HXJ225 |
||
|
Structure type |
Skid module type |
||
|
Workover depth (ft) （31/2″DP） |
———— |
||
|
Drilling depth (ft) （5″DP） |
10000 |
||
|
Max. hook load (lbf) |
500000 |
||
|
Engine model |
2 ×C15 |
||
|
Engine power (hp) |
2 ×475 |
||
|
Transmission box model |
2 × S5610H |
||
|
Transmission type |
Hydraulic +mechanical |
||
|
Derrick structure/ Height (ft) |
K type/102、108 |
||
|
Traveling system |
5×4/6×5 |
||
|
Drilling line diameter (in) |
1 1/4 |
||
|
Rotary table model |
ZP275 |
||
|
Traveling block model |
YG225 |
||
|
Swivel model |
SL225 |
||
|
Rated power of mud pump (hp) |
1000/1300 |
||
|
Substructure height (ft) |
20 |
||
|
Working environment |
Limit wind speed (knot) |
107（without setback） 93（full setback） |
|
|
Earthquake magnitude |
8 |
|
|
|
Temperature ℃ |
-20～+40 |
|
|
|
Relative humidity |
≤98% |
||
