YJ240AX1 right cable outlet motor

Rate:

0.0000/5

( 0 reviews )

Item NO.: V024603 MOQ: 0

Weight: 6200kgs

Package Size:

Price：

$56522.00

Qty：

$56522.00

Shipping：

Calculate Shipping Cost

YJ240AX1 right cable outlet motor

delivery time：2 months

YJ240AX1 right cable outlet motor parameters
motor model	YJ240AX1
rated power	1100 kW
Rated voltage	600 V
Rated current	1240A
Power factor	0.88
Rated efficiency	93%
Rated frequency	25.4 Hz
Rated speed	500 r / min
Rated torque	21000 N • m
Maximum speed of constant power	1650r / min
Pole number	6
Insulation class	200
cooling method	Forced ventilation
Working system	Continuous S1
Protection level	IP44
Explosion-proof grade	ExdeIIBT3
Ambient air temperature	0 ° C ~ + 50 ° C
relative humidity	Up to 97%

NO Model rated power (KW) Rated voltage(V) Rated current(A) Rated speed(r/min) Rated frequency(Hz) Rated torque(N•m) Constant work speed(r/min) box location (From the transmission side) Explosion-proof sign

1 YJ23M 400 600 480 661 33.5 5779 1339 Left ExdeⅡBT3 Gc

2 YJ23MX1 400 600 480 661 33.5 5779 1339 Left ExdeⅡBT3 Gc

3 YJ23L2 600 600 682 1000 50.5 5730 1730 Right ExdeⅡBT3 Gc

4 YJ23L3 600 600 682 1000 50.5 5730 1730 Left ExdeⅡBT3 Gc

5 YJ23F9 600 600 714 661 33.5 8669 1240 Left ExdeⅡBT3 Gc

6 YJ23F9X1 600 600 714 661 33.5 8669 1240 Right ExdeⅡBT3 Gc

7 YJ23L10 600 690 605 661 33.5 8669 1200 Left ExdeⅡBT3 Gc

8 YJ23L10X1 600 690 605 661 33.5 8669 1200 Left ExdeⅡBT3 Gc

9 YJ23K4 700 690 716 1000 50.5 6685 1880 Left ExeⅡT3

10 YJ23K5 700 690 716 1000 50.5 6685 1880 Right ExeⅡT3

11 YJ31J 720 600 826 600 30.5 11460 1184 Right ExeⅡT3

12 YJ31J1 720 600 826 600 30.5 11460 1184 Left ExeⅡT3

13 YJ31B6X1 720 690 756 600 30.5 11460 1105 Right ExeⅡT3

14 YJ31B6X2 720 690 756 600 30.5 11460 1105 Left ExeⅡT3

15 YJ13A8 800 600 960 741 37.5 10310 1485 Left ExeⅡT3

16 YJ13A9 800 600 960 741 37.5 10310 1485 Right ExeⅡT3

17 YJ31H6 800 690 830 741 37.5 10310 1385 Left ExdeⅡBT3 Gc

18 YJ13A13 800 690 826 1000 50.5 7640 1750 Left ExdeⅡBT3 Gc

19 YJ13A13X1 800 690 826 1000 50.5 7640 1750 Right ExdeⅡBT3 Gc

20 YJ23N1 900 600 1020 1100 55.5 7814 1675 Left Exdepz ⅡBT4 Gc

21 YJ23N1X1 900 600 1020 1100 55.5 7814 1675 Right Exdepz ⅡBT4 Gc

22 YJ31F7 1000 600 1140 803 40.6 11893 1205 Left Exdepz ⅡBT4 Gc

23 YJ31F7X1 1000 600 1140 803 40.6 11893 1205 Right Exdepz ⅡBT4 Gc

24 YJ31E5 1200 600 1380 1000 50.5 11460 1500 Right Exdepz ⅡBT4 Gc

25 YJ240A 1100 600 1240 500 25.4 21010 1650 Left ExdeⅡBT3 Gc

26 YJ240AX1 1100 600 1240 500 25.4 21010 1650 Right ExdeⅡBT3 Gc

27 YJ243A 970 660 1023 794 40 11667 1880 Left ExdeⅡBT3 Gc

28 YJ243AX1 970 660 1023 794 40 11667 1880 Right ExdeⅡBT3 Gc

29 YJ243B 860 660 914 792 40 10370 1800 Left /

30 YJ243BX1 860 660 914 792 40 10370 1800 Right /
